1PV2V4-30/32RA1MC016A1 VARIABLE VANE PUMP: STRUCTURE, PERFORMANCE AND INDUSTRIAL APPLICATIONS
Oct 12, 2026
Product Introduction
The 1PV2V4-30/32RA1MC016A1 is a dual-stage variable vane pump designed for hydraulic drive systems. It combines a fixed displacement front pump and variable rear pump in one compact housing, delivering adjustable flow output to match system load demands. This unit converts mechanical rotation into hydraulic fluid pressure energy, supporting continuous pressure supply for medium-pressure hydraulic circuits.
The pump adopts precision vane and cam ring structure, featuring low noise operation, stable pressure output and easy flow adjustment. Its integrated design reduces installation space and simplifies pipeline layout. It maintains reliable performance under continuous cyclic working conditions, with good resistance to oil contamination. The pump is widely preferred for machinery requiring energy-saving variable control, helping lower power consumption and heat generation of the whole hydraulic system.
Application Scenarios
This 1PV2V4 series combined vane pump is widely used in stationary industrial machinery and light mobile equipment requiring stable medium pressure hydraulic supply, covering multiple core industries:
1. Machine Tool Industry
It serves as the hydraulic power source for injection molding auxiliary machines, metal cutting lathes, grinding machines and hydraulic presses. The adjustable flow characteristic allows flexible matching of feed speed and clamping force, ensuring precise and smooth action of machine tool actuators while reducing idle power loss.
2. Material Handling Equipment
The pump is applied to hydraulic stations of pallet lifting machines, small stackers and conveyor drive systems. Its compact size and stable pressure performance support frequent start-stop operation, improving the response speed and operation reliability of material handling equipment.
3. Light Engineering Machinery
It can be configured on small road maintenance machines, concrete spraying auxiliary devices and portable hydraulic power units. Thanks to low-vibration and low-noise features, it works steadily in semi-outdoor workshop environments and meets the long-running demands of light construction tasks.
