EDS Truck Construction Machinery Hydraulic Control Valve HDA 8446-A-0100-000 SENSOR

MCV116G4201 is a high performance pressure control valve designed for heavy-duty mobile hydraulic circuits. It is built to regulate system pressure, prevent overload and protect pumps, motors and other sensitive hydraulic components from pressure spikes during sudden load changes. Compact body layout allows flexible mounting on manifold blocks or directly fitted to main pumps, which saves installation space inside narrow equipment cabins.

HDA Series Hydraulic Control Valve SENSOR
This high-precision hydraulic pressure sensor adopts advanced ceramic sensing core for accurate pressure signal acquisition.
Features ultra-low signal drift, sustaining stable detection data during long-term uninterrupted monitoring.
Dustproof and waterproof grade structure, resisting moisture and particle erosion in field working conditions
Compact integrated structural design, enabling quick and embedded installation in hydraulic systems.
Fine calibrated measuring range, realizing high-resolution real-time pressure monitoring and feedback.
Integrated surge and interference resistance design, adapting to complex electromagnetic industrial scenes.
Equipped with standardized electrical output signal, perfectly compatible with mainstream industrial control modules.

HDA Series Hydraulic Control Valve SENSOR Data Sheet

product-518-419

3. HDA Series Hydraulic Control Valve SENSOR Core Advantages

Compact body structure, easy to mount on narrow pipeline space.

Low temperature drift, maintains consistent reading under varying ambient temperature.

Robust stainless steel housing resists vibration and shock, suitable for mobile machinery.

Ceramic sensing diaphragm features strong media compatibility, adapts to hydraulic oil and many non-corrosive liquids.

Standard 4-20mA signal, good anti-interference for long distance signal transmission.

Simple wiring and installation, reduces on-site commissioning time.

4. HDA Series Hydraulic Control Valve SENSOR Application Scenarios

Mobile construction machinery: Excavator auxiliary hydraulic circuit, loader working pressure monitoring, crane hydraulic power system.

Stationary hydraulic power pack: Injection molding machine hydraulic station, metal cutting machine hydraulic control loop, hydraulic press pressure feedback.

Material handling equipment: Forklift hydraulic lifting system, conveyor hydraulic tension control.

Industrial process monitoring: Water and oil pipeline pressure detection, cooling system pressure supervision.

Filter condition monitoring: Differential pressure detection for hydraulic return filter and pressure filter, early warning of filter clogging.
