High Pressure Hydraulic Cartridge Brake Valve R900427591 LT06-A06-3X/150B40/02M Container Lifting Machinery Hydraulic Control Valve

This is an EIPC3 series internal gear pump, rated size 032, with constant displacement volume, designed for industrial hydraulic applications and speed-regulated stationary hydraulics. Axial and radial gap compensation together with radial compensating segments deliver high volumetric efficiency, low noise and low pulsation (about 2 percent). The robust aluminum housing and SAE 2-hole flange make it a preferred fixed-displacement pump for servo-driven injection molding machines and industrial power units.

LT 06 Series Hydraulic Cartridge Brake Valve
It integrates charging, pressure holding and brake locking functions for mobile lifting machinery
Controlled by pilot oil to release brake smoothly and avoid sudden impact on loads
Fast valve reset cuts off oil circuit instantly to prevent load slipping and downhill drifting
Stable preset pressure rating supports consistent brake protection under heavy load cycles
Compact body layout saves installation space on reach stacker and handling equipment
Precision spool machining reduces internal leakage and maintains long-term holding performance
Standard mounting interface facilitates direct replacement and quick field maintenance

EIPC Series Hydraulic Cartridge Brake Valve

product-779-622

LT 06 Series Hydraulic Cartridge Brake Valve PERFORMANCE HIGHLIGHTS

LT 06 series cartridge-type solenoid valve

Accumulator charging / brake pressurizing function

Set pressure range around 150 bar class (150B40)

Integrated solenoid actuation

Cartridge mount for direct replacement

For material handling machine hydraulic circuit

Unloads pump after accumulator reaches set pressure

LT 06 Series Hydraulic Cartridge Brake Valve Application Scenarios

This LT06 accumulator charging valve is designed for hydraulic brake accumulator circuits of mobile working machinery. It maintains a stable preset pressure of 150 bar inside the brake accumulator, automatically supplementing oil when pressure drops below the set threshold and stopping charging once the target pressure is reached. It integrates charging, pressure holding and brake locking functions for safety brake circuits.

It is widely fitted on reach stackers (container stackers) and other port handling equipment, as well as a broad range of construction and mobile hydraulic machines including forklifts, wheel loaders, forestry machines, agricultural machinery and municipal special vehicles.

During normal operation, control oil opens the valve port to charge the brake circuit and release the hydraulic motor brake for equipment travel and lifting actions. When system pressure is lost or the machine stops, the valve resets rapidly to seal the oil circuit, locking the hydraulic motor to prevent load sliding, rolling away or accidental descent. It provides fail-safe holding protection for travel and hoisting loads, complying with mobile machinery safety requirements. The compact modular design supports easy integration into customized hydraulic brake blocks.
