| EIPC Series Hydraulic Gear Pump |
|
| High Pressure Internal Gear Pump | |
| Low noise and stable output flow, long service life. | |
| Compact structure, easy installation and maintenance | |
| Ultra-low pressure pulsation | |
| Servo variable speed hydraulic systems gear pump | |
| Easy installation and maintenance. | |
| Wide speed range, stable performance under long-time continuous heavy load operation. |
EIPC Series Hydraulic Gear Pump
EIPC Series Hydraulic Gear Pump PERFORMANCE HIGHLIGHTS
This fixed displacement internal gear pump adopts axial and radial segment gap compensation structure.
It maintains stable volumetric efficiency even under long continuous high pressure operation.
Ultra low pressure pulsation helps reduce vibration and stabilize the whole hydraulic system.
It supports continuous working pressure up to 250 bar for heavy duty industrial scenarios.
Radial layout of suction and pressure ports brings flexible pipeline connection options.
The pump runs quietly, suitable for servo hydraulic and precision machinery systems.
Wide available speed range meets diverse operating condition requirements.
Compact overall structure simplifies installation and saves layout space of equipment.
EIPC Series Hydraulic Gear Pump Application Scenarios
Injection molding machines: plastic injection moulding machine, servo energy-saving injection machine
Rubber machinery: rubber vulcanizing machine, rubber extrusion machine, hose crimping machine
Metal forming equipment: hydraulic press, bending machine, die casting machine
Industrial hydraulic power units: servo hydraulic station, material compacting machine, cutting machine
Other industrial equipment: paper making machinery, lifting and conveying equipment, wind power auxiliary hydraulic system
Related Available Hydraulic Gear Pump in EIPC Series
EIPC3-032RA23-10
EIPC3-032RA23-1X
EIPC3-020RA23-10
EIPC3-025RA23-10
EIPC3-040RA23-10
EIPC3-050RA23-10
EIPC3-064RA23-10
EIPC3-080RA23-10
EIPC3-100RA23-10
EIPC3-125RA23-10
EIPC3-160RA23-10
EIPC3-200RA23-10
EIPC3-250RA23-10
