Oil Hydraulic Pressure Medium Pressure Control Valve JGH HG-03-C3-22 HCG 06 10 C1 C2 C4 B1 B2 B3 B4 A1 A2 A3 HCG-06-C2 HG-06-C2

Oil hydraulic pressure medium pressure control valve Instructions Sub-plate To adjust the pressure, loosen the lock nut and turn the pressure adjustment screw slowly clockwise to increase pressures or anti-clockwise to decrease pressures. After adjustments, do not forget to tighten the lock nut. Connect the secondary side pressure ports of types 1 and 4 (internal drain) and the drain ports of types 2 and 3 (external drain) directly to the reservoir with a back pressure close to the atmospheric pressure. There are two threaded connection primary pressure ports. They can be connected each other in-line; one as inlet and the other as an outlet or the valve can be used by plugging one of the pressure ports.

Oil hydraulic pressure medium pressure control valve JGH HG-03-C3-22 HCG 06 10 C1 C2 C4 B1 B2 B3 B4 A1 A2 A3 HCG-06-C2 HG-06-C2

H Type Pressure Control Valves HC Type Pressure Control Valves There are various types of valve including sequence, unloading and low pressure relief valves, all of which are operated by a pressure rise in the circuit, sensed either internally or remotely. They are available with integral check valves for use when free reverse flow from secondary port to the primary port is desired. There are various types of valve including sequence and counterbalance valves, all of which are operated by a pressure rise in the circuit, sensed either internally or remotely
