IPV Series IPV-6-100-101 IPV5-64-101 IPV6-80-101 IPV6-125-101 Hydraulic High-pressure Internal Gear Pumps

hydraulic High-pressure Internal Gear Pumps By rotation of the gears inside the pump, the pressure fluid (usually hydraulic oil) is drawn into the cavity between the pinion and internal gear. Optimized cross-sectional areas on suction side as well as on pressure side allow operation over a wide range of speed. In the radial direction, the gear chambers are closed by gear meshing and the filler piece. In the axial direction, the axial plates seal the pressure chamber with the minimal possible gap. This design minimizes volume losses and increases efficiency.

Send Inquiry

Description

IPV Series IPV-6-100-101 IPV5-64-101 IPV6-80-101 IPV6-125-101 hydraulic High-pressure Internal Gear Pumps

• Pumping of mineral oils with a viscosity of 20…40 mm2s-1 • An input pressure of 0.8…3.0 bar absolute Notes • Peak pressures apply for 15 % of operating time with a maximum cycle time of 1 minute • Please inquire about peak pressures at non-standard speeds • Due to production tolerances, the pump volume may be reduced by up to 1.5 %.
