| PVV blade pump product introduction: |  |
| ■ 20 different displacements, ranging from 18cc/rev (1.1 cu/in/rev) to 193cc/rev (11.8 cu/in/rev) | |
| ■ Hydraulic balance design provides long bearing life | |
| ■ Ink cartridge replacement simplifies service and maintenance | |
| ■ Ink cartridges are interchangeable with competing designs | |
| ■ Replacement can be easily performed by swapping ink cartridges | |
| ■ The rotational flexibility of port position optimizes the customer interface |
PVV blade pump specifications:
PVV blade pump parameter specifications:
Working principle of vane pump:
When the rotor of the vane pump rotates, the tips of the blades are tightly attached to the inner surface of the stator under the action of centrifugal force and pressure oil. The working volume formed by the two blades and the inner surfaces of the rotor and stator first absorbs oil from small to large, and then discharges oil from large to small. When the blades rotate once, they complete one oil absorption and discharge.
PVV vane pump product model:
219602 PVV2-1X/018RA15DMB
219603 PVV2-1X/027RA15DMB
219604 PVV2-1X/036RA15DMB
219605 PVV2-1X/040RA15DMB
219606 PVV2-1X/046RA15DMB
PVV21-1X/060-040RA15DDMB
PVV21-1X/068-027RA15LUMB
PVV41-1X/098-027RA15UDMC
PVV41-1X/122-036RA15DDMC
PVV42-1X/098-045RA15DDMC
PVV21-1X/068027RA15LUMB
PVV51-1X/162-036RB15DDMC
PVV51-1X/193027RA15DDMC
PVV52-1X/193-040RB15URMC
PVV52-1X/193-055RB15UUMC
PVV54-1X/183-082RA15DDMC
PVV54-1X/139-082RA15UUMC
PVQ2-1X055RA15DLMB
PVQ2-1X068RA15DLMB
