| Up to 480 bar, with high output power capability |
|
| Supports extremely high shaft speeds (up to 7300 revolutions per minute), with ball plunger design optimized for high-speed performance | |
|
Provide bidirectional (M-type) or unidirectional (L/R type) options, suitable for various flange and shaft extension requirements |
|
|
The angle between the shaft and the cylinder body is 40 °, achieving lightweight and miniaturization |
|
|
Stacked piston rings reduce internal leakage and thermal shock, and heavy-duty roller bearings can withstand high axial/radial loads |
|
|
Low number of parts, piston locking and timing gear design improve reliability |
|
|
F11 Hydraulic Piston Motor Parameter Table:
|
|
About Us:
The main business of Ningbo Lainuo Hydraulic Technology Co., Ltd. is the design, research and development, production, sales, and professional technical services of hydraulic piston pumps, hydraulic cylinders, and hydraulic systems. We can provide customers with comprehensive hydraulic transmission solutions. The high-end hydraulic pumps, hydraulic motors, reducers, and multi way control valves produced by the company have broken through the foreign technology blockade and achieved the localization of servo digital hydraulic systems. Currently, it has more than 140 series and over 500 products, and is committed to focusing on professionalism, innovative development, and providing environmentally friendly, intelligent, efficient, and durable high-end hydraulic products for human labor.
F11 Hydraulic Piston Motor Product Advantages:
1.High-Power Density Design,Compact axial piston structure with a 40° swash plate angle, delivering robust torque output in a lightweight package.
2.Extended Durability,Reinforced roller bearings and laminated piston rings withstand extreme axial/radial loads, minimizing internal leakage and thermal stress.
3.Broad Operational Range,Continuous operation at 350 bar (5,075 psi) and peak pressure of 480 bar (6,963 psi), compatible with high-speed applications up to 7,300 rpm.
4.Versatile Mounting Options,Supports ISO/SAE flange standards with bidirectional (MB) or unidirectional (IV) shaft configurations for flexible system integration.
5.Low-Maintenance Reliability,Simplified architecture with fewer moving parts, featuring piston locking and timing gears for reduced wear and extended service life.
2. Industrial hydraulic systems, injection molding machines, die-casting machines
3. Ship and port machinery, deck crane, winch and other ship equipment
4. Hydraulic systems for mining equipment, mining trucks, and rock drills.
F11-006-MB-CN-K-331-000-0
F11-010-MB-CV-K-396-000-0
F11-010-MB-CV-K-209-0000-0X
F11-010-MB-SH-K-000
F11-010-SB-CV-K-000
F11-010-RB-CV-K-000
F11-015-MB-IV-K-000
F11-019-MB-CN-K-000
F11-039-MB-CV-K-000
F11-150-MF-CN-K-000
F11-150-MF-CV-K-000
F12-040-RF-IV-K-000-0000-P0
F12-060-MF-IV-K-000
F12-080-MB-CV-K-000
F12-110-MF-IV-000-0000
F12-150-MB-CN-K-000
F12-200-RF-IV-K-000
F12-250-MB-CV-K-000
F12-300-SB-IV-K-000
